high quality stainless steel wire rake screen for large city sewage treatment plant
2 sets
MOQ
USD 5000-200002
Price
high quality stainless steel  wire  rake screen for large city sewage treatment plant
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: LI
Model Number: LIWP-300/500/600/800/900/1000/1200/1500
Payment & Shipping Terms
Packaging Details: Wooden box
Delivery Time: Within 45 days for 20GP
Payment Terms: T/T or western union
Supply Ability: 1000 sets per season
Specifications
Max. Width Of Well: 3M
Max. Depth Of Well: 10M
Screen Gap Available: 1, 3, 5, 10,15, 20,30,40,50 Mm
Mounting Angle: 60, 70,80 Degree
Sequence Gear Material: Nylon, SS.304, SS316L, 2205, 23750 Available
Max Capacity For Single Unit: 10000 M3 Per Hour
Flow Speed: 0.5-1 M/s
Product Description

WP  Rotary solid-liquid separator

Brief introduction

It is special water treatment equipment for continuously and automatically intercepting and removing various shapes debris in the fluid.

It has widely applied in urban sewage treatment, waterworks industry, and power plant intakes; meanwhile it can be also used as pre-screening equipment in wastewater treatment process of textiles, food processing, paper, leather and other industries.

high quality stainless steel  wire  rake screen for large city sewage treatment plant 0

Working principle

It is composed by special rake chains which will be back rotating from water flow direction under motor reducer.

When rake chain arrives at its upper end , each group of rake  will carry on self cleaning by dropping out most of the solid material under gravity and guideline rail,while the rest of the solid will be tidied clean by back running brush.

The rake gap can be choose as per on site condition, and the working can

Be design as continuously or sequent running





Features

The biggest advantage of this device is: Fully automation, high separation efficiency with little power consumption, no noise, good corrosion resistance, it can be also in continuous and stable running with overload protection device, auto shut down device under fault or fail set-up to  avoid equipment overload.

Running sequence time can be adjustable freely and controlled by front and backward liquid level gap with hand control function to facilitate maintenance.

Simple and reasonable design make it has strong self cleanness with little daily maintenance and little jam phenomena.

Technical Parameter and Model Selection

1.Device and Rake specification

Machine can be divided into HF300-3600 as per its width

And its rake gap can be 1mm, 3mm, 5mm, 10mm, 20mm, 30mm, 40mm, 50m etc.

The model selection depends on water flow, mounting height, solid liquid

Separating total volume and separated material shape, grain size to

choose best material and solution model.



2.Bar screen specification

Standard channel depth is 1535mm,customized stipulated size can be design

specially as per demand.

Water flow table for model selection reference

Model

WP-300

WP500

WP600

WP800

WP900

WP1000

WP1200

WP1500

Front water depth

1.0( m )

Flow speed

0.5--1.0 ( m/s )



Rake Gap

mm



1



Water flow volume

m/h

150

240

300

430

500

580

700

900

3

300

475

625

880

1000

1160

1430

1800

5

375

600

760

1080

1250

1450

17500

2000

10

450

730

900

1300

1450

1750

2080

2250

20

460

750

950

1400

1580

1800

2250

2400

30

600

975

1200

22100- 44200

2000

23800

2900

3100

40

650

1200

1500

1800

2600

3000

3700

4800



50

850

1500

2000

3000

3400

3900

4700

6000

Comment dual connection machine water flow volume :2 times of above value.

For example: GF2000 equals to 2 sets GF1000 with rake gap 10mm and flow volume between 1750m and 3500m³per hour.
