Product Details:

Place of Origin: Huaibei , China
Brand Name: Loren
Certification: ISO CE
Model Number: NXZ series

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Packaging Details: naked and firm packing for essential parts
Delivery Time: 25 working days
Contact Now
Detailed Product Description
Material: Epoxy Cabaron Steel Or SS Feature 1: Lifting Mechanism
Feature 2: Large Capacity Feature 3: Excellent Efficiency
Style Optional: Speed And Rake Boosting Unit Award: Technical Advanced Prize
Applicant: Coal And Mining

this is our essential mining thickener with rake lifting mechanism to export many overseas and domestically

Copper, Zinc , Gold and other Metal Mining Tailing Center Drive Rake Lifting Slurry /Scum/Sludge Thickener

Loren Center Drive Rake Lifting Mechanism Slurry , Scum Thickener and Scraper for Mining Tailing Slurry Classification

Structure Feature and Advantage

1.with 2 or 3 Hydraulic Drive Device to safeguard stable running Status

2. With deep tangential feed, advection settlement and automatic dilution

3.Adopt Higher Rake Speed with Higher HIP , Large Floor Floor Density

4. Rake speed can be adjustable to realize stepless or poleless speed

5. Seamless Steel Rake Support Body reduces power consumption, water resistance to enhance its strength and increase flotation power.

6. Adopt Special Designed Screw Blade.

7. Idea Good Design due to high efficiency Large Performance Sites

8. The good design on feeding system (view general diagram)

9. Reliable Lubricated system

10. Hydraulic Pump Station And Control System.( Essential Part)



Loren Center Drive Rake Lifting Mechanism Slurry , Scum Thickener and Scraper for Mining Tailing Slurry Classification

System Composition

It Is Composed of Driving Device, Bridge, Concrete Ponds, Cage, Rakes, Fabric Tube, Hydraulic Station, Electric Control Boxes And Other Components.

Loren Center Drive Rake Lifting Mechanism Slurry , Scum Thickener and Scraper for Mining Tailing Slurry Classification

NXZ Lifting Mechanism Center Drive Thickener Parameter



Model



Height

mm



Settler

Area m²

Rake Shaft Speed

RPM

Rake Speed

mm/min

Rake Lift Height

mm



Capacity

M3/h



Motor Power

kw



Weight

kg



NXZ6 3100 28.27 2.5~5 150 350 60~80 3 5297
NXZ8 4782 50 3~5 150 500 100~200 7.5 18310
NXZ9 2918 63.6 2~10 150 400 125~190 4 12576
NXZ12 5990 113 2~10 150 400 280~340 4 16643
NXZ15 4794 176 5~15 150 400 440~530 5.5 18792
NXZ16 4396 201 5~15 150 450 500~600 5.5 19826
NXZ18 5050 254 5~20 150 450 635~760 5.5 21638
NXZ20 5144 314 5~20 150 500 785~940 7.5 26977
NXZ21 5241 346 5~20 150 450 865~1040 7.5 28096
NXZ22 6776 380 5~20 150 450 950~1140 7.5 29134
NXZ24 6250 452 5~20 150 450 1130~1357 7.5 31998
NXZ30 5915 706 10~20 150 450 1765~3120 7.5 39775
NXZ35 6955 962 10~20 150 600 2405~2885 14 47950
NXZ38 6323 1134 10~20 150 600 2835~3400 14 51073
NXZ20 7220 314 5~20 150 500 ~1500 11 36299
NXZ24 7664 452 10~20 150 500 ~2100 11 55673
NXZ30 8325 706 10~20 150 500 ~1500 18.5 68581

Loren Center Drive Rake Lifting Mechanism Slurry , Scum Thickener and Scraper for Mining Tailing Slurry Classification
