2021 new style oil bath style air filter
2 Sets
2021 new style oil bath style air filter
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: Loren
Certification: ISO9001:2008
Model Number: LIOF-500-B
Payment & Shipping Terms
Packaging Details: standard export or as per buyer's demand
Delivery Time: Within 45 days for container order
Payment Terms: T/T; Paypal; L/C at sight, others
Volume Flow: 17000 Cubic Meter Per Hour
Cylinder DN.: 1500MM
Inlet And Outlet Pipeline DN: 500MM
Outer Dimension: 1650×1630×2150mm
Filtering Effect: 99.5%
Filtering Accurancy: Under 0.003
Resistance: Under 500pa
Product Description

In the air, the impurities like dust are contained, the dust density in the clean air is less than 1mg/m3 and that of dust air between 1000~3000mg/m3. The main component of particles in air is silicon oxide which cover 60~80% or even 90~95% sometimes of the total,

While the remains are the organic substance and the oxides of calcium, aluminum and iron. The particles sized between 10~30um in air will enhance the wear between the cylinder bush and piston of the engine or compressor. So, the air filter is an indispensable component of the engine or air compressor.Air filter is such important ancillary equipment for air compressor or diesel engine with working media by air. Its role is to reduce the dust and other impurities in the air absorbed by air compressors or diesel engines. These dust and impurities will adhere to other valves through entering the compression chamber to reduce the production capacity of air compressor or diesel engine as well as to wear moving parts thus to shorten the life of the compressor or the diesel engine. If suction temperature is too high, some impurities and oil adheres to the valves to be carbonize quickly and reduce the ventilation hole cross-sectional area of valve, meanwhile it will also reduce air compressor productivity or damage the working status of the diesel engine

2021 new style oil bath style air filter 0                                 Air through the oil bath air filter, the dust content in air is less than required 1mg/m3, resistance is not greater than 50mm water column, so we suggest to use it matching the normal performance of air compressor or diesel engine to guarantee its significance on bad working condition such as cement plants, desert area etc.

Feature: it removes out the dust in the air through such ways as the cyclone, oil bath, oil foaming, oil film and filter mesh with 99.5% filter efficiency and filter accuracy no more than 0.003mm as well as resistance no more than 50mm water column to reach low noise, high efficiency and small filter resistance .so it won’t accumulate dust and no need to clean and replace it frequently.
