|Cod Removal Ratio:||30%-80%||Oil And TSS Removal:||Over 90% With 1 Ppm|
|Turbidity Reduced:||Can Reach Below 3 NTU||SiO2 Wipe Out:||70%-90% Compare Other 30-40%|
|Heavy Metal Ion Reduce:||80%-95%||Chroma,(8) Bacteria, Viruses Reduced:||Over 80%|
|Free Maintenance:||For 2 Years||Little:||Investment|
|No:||Operating Charge And Little Maintenance Cost||Small:||Footprint|
|Run:||Simplely , Easily And Automatically||Little:||Sludge Happened|
|Fast And Flexible:||Design , Make And Service|
The electrocoagulation method can be used alone or in combination with other treatment methods, such as pretreatment method, which can improve the biodegradability of wastewater; generally for refractory organic wastewater, such as pharmaceutical, chemical, fuel industry wastewater and contains refractory treatment The toxic substances have a good treatment effect. Electro-flocculation is mainly used to remove heavy metals, suspended solids and emulsified organic matter in wastewater. It has been widely used in petroleum and petrochemical industries, electroplating industry,non-ferrous metal smelting industry and ship bottom sewage treatment. The treatment effect of the process on pollutants is shown in the following table:
Application of electroflocculation in treatment of high concentration organic wastewater
When the high-concentration biochemical and non-biochemical organic wastewater is treated by the traditional process, the traditional process is used, the process is long, the operation cost is high, the load is high, and the effect is not obvious; the electroflocculation has been successfully used for such wastewater treatment, Under the action of electric charge, biochemical and non- biochemical organic matter directly breaks the molecular bond and degrades COD. For example, high-concentration organic wastewater in slaughtering and aquaculture, high-concentration wastewater in food plants, alkane-containing wastewater in petroleum industry, textile printing and dyeing wastewater, etc.
Application of electroflocculation in treatment of high ammonia nitrogen wastewater
In the treatment of high ammonia nitrogen wastewater, electroflocculation also has a good treatment effect, which has been applied to the treatment of garbage leakage.
Application of electroflocculation in the treatment of electroplating wastewater (including heavy metals)
Electro-flocculation in the treatment and reuse of electroplating wastewater can overcome the problems that are difficult to solve by chemical treatment. It can not only effectively remove heavy metal ions in electroplating wastewater, but also reduce the salt content in water, so that the treated water can be recycled and reused. Process. Electroplating wastewater treated by electroflocculation can achieve the following treatment effects: Cr<0.001, removal rate up to 100%; Ni<0.005 removal rate up to 100%; Zn<0.062 removal rate up to 57%.
Application of electroflocculation in the treatment of fluorine- containing wastewater
In some developing countries, such as China, Egypt, India, etc., fluorosis is an endemic disease with a long-term comparison. Therefore, the defluoridation problem of drinking water has become a popular direction. The methods of removing fluorine include: lime precipitation method, coagulation sedimentation method, adsorption and ion exchange method, electrocoagulation method, electrodialysis method, reverse osmosis method, etc.
Electrocoagulation is a more competitive method.
Application of electroflocculation in dye (high chroma) wastewater treatment
Dye wastewater has the characteristics of high COD, high chroma, high salt content, and difficult organic degradation of organic matter. In the past, it has been generally treated by a combination of physicochemical methods and biological methods. However, due to the complicated drainage composition, the handling difficulty is still large. With the development of electroflocculation technology, electrocoagulation treatment of dye wastewater has the advantages of small equipment, small land occupation, simple operation management, high COD removal rate and good decolorization effect.
Application of electroflocculation in wastewater treatment of shipyards
(including emulsified oil and heavy metals) Electroflocculation has a unique effect in the treatment of oil latex, SS, organic matter. Can be widely used in petrochemical, paint dyes, pigments and other wastewater, car wash wastewater, oil field wastewater and other fields.
Technical characteristics of the equipment
Equipment operating costs
Power consumption: According to different water treatment requirements, the electricity consumption per ton of water treated is 0.1-1.5kWh.
Plate loss: According to different water treatment requirements, the cost of plate consumption is 0.01-0.03 CN RMB / ton of water.
Electric flocculation operation cost: 0.06 - 0.78 CN RMB / ton of water (electricity price is 0.5 CN RMB / kW)
Equipment operation instructions
The electric flocculation can be installed at the location near the treatment site, and the power control cabinet should be placed in the drying equipment room. If there are special explosion-proof requirements, it needs to be explained in advance.
Method of operation
The equipment is a continuous automatic operation mode, and no special care is required. The water inlet is provided with a flow meter, and the flow rate can be controlled by the valve. The water is pressurized by the pump into other processing systems, or directly discharged, and the equipment discharge can be set to manual or automatic control according to requirements.
