Factory Sell LACF-8 High Efficiency Activated Carbon Filter
1 Set
Factory Sell LACF-8 High Efficiency Activated Carbon Filter
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: Loren
Certification: ISO9001:2008
Model Number: LACF-8/20/30/50/70
Payment & Shipping Terms
Packaging Details: standard export or as per buyer's demand
Delivery Time: Within 45 days for container order
Payment Terms: T/T; Paypal; L/C at sight, others
Supply Ability: 20 set per month
Rated Clean Water Capacity: 7.8-71 Cubic Meter Per Hour
Input SS: ≤20-100mg/l
Oupput SS: 1-5 M3/h•m2
Design Filtering Speed: 10-20m/h
Washing Toughness Of Filtering Tank: 0.6-3l/m2•s
Washing Toughness: T=10-20min(adjustable )
Running Temp.: 10- 50℃
Running Pressure: Lower Than 1.0 MPa
Product Description

Automated Mechanical Filter Helps Water Purifier Performance

Why us?

1. Factory Long History Directly Sales Cost and Fast Delivery

2. Fully Combined Sewage Treatment Solution Design And Fabrication

3. Fully Automatic System with Long Life Work Protection

4. High Efficiency Activated Carbon Filter

5. Within 8 Hours Response Service and After Sales Service


Feature and Performance

  • Highly Reduce COD and Disaffection As Well As Other Pollutant
  • Can be Designed as AC Regeneration online
  • Upper Water Inlet From is Mother And Branch Pipes Design .
  • Down-forward Water Outlet Form Is Perforated Plates Water Cap
  • With On-Site Sampling Device and Water Pressure Gauges.


Applicant of The Activated Carbon Filter

  • Remove Macromolecular Organic Matter In Water
  • Remove Iron Oxides In Water
  • Remove Residual Oxygen In Water
  • Remove Organic Matter In Water
  • Remove Iron Oxide In Water
  • Prevent Ion Exchange Resin Poisoning (Disinfection)


Activated Carbon Filter Parameter


Model Filter DN (mm) Filter Area m2







AC Layer Height mm
1 LACF-8 1000 0.78 8 DN1012*4800 8-10 m/h 2000
2 LACF-20 1500 1.76 20 DN1516*6025 8-10 m/h 2000
3 LACF-30 2000 3.14 30 DN2020*6430 8-10 m/h 2000
4 LACF-50 2500 4.90 50 DN2524*6460 8-10 m/h 2000
5 LACF-70 3000 7.1 70 DN3028*6590 8-10 m/h 2000



  • The Valve normally Provided By user , if needed , specify when ordering
  • Restart The Filter After Long Time Stop, Before Reuse , Flushing The AC Media For 5 Mintues Till The Water Become Clear Again.
  • Restart The Filter After Long Time Stop, Before Reuse ,Open The Air Valve and Water Inlet Till The Air Valve Outlet Water Has No Air
  • Large Filter Use air(strength 8L/m2 S) Scrubbing To Enhance The Back washing Effect before Air-Water Backwashing
  • The AC Media Should Be Replaced Regularly ( Usually Every 3-6 Months) as Per Water Quality .

Factory Sell LACF-8 High Efficiency Activated Carbon Filter 0
